KIA Sportage is a compact SUV for the US market in 4 generations, models, and trim levels. You can find a number of its used parts in junk yards and online stores that are interchangeable in specific variants of the SUV.
What Year Kia Sportage Parts Are Interchangeable? According to our research, you can interchange different parts of Kia Sportage from 1995 to 2021. Its 1st generation from 1995-2002 models is unique from the rest of the variants, and its parts are compatible with the SUV of the same year or 1-2 adjacent years. You can replace most parts of the 2nd generation, including engine, ignition, drivetrain, body, and electrical parts, between the 2005-2009 variants. The 3rd generation had a facelift in 2014, and you can swap its parts between the 2011-2013 and 2014-2016 models. You can swap most parts with few exceptions in the 4th generation from 2017-2019. AWD and FWD have all parts identical except the drivetrain.
This SUV has 4 generations available in 1995-2022 models and 5th generation to introduce in 2023 for the US market.
Moreover, besides the complete system, there is also an option for swapping the individual components.
Ignition parts
Its ignition system includes components like the ignition switch, ignition coils, spark plugs, and other electronic parts that are also part of chassis control and ECM.
Ignition switch is interchangeable within 1995, 1996-2000, 2001-2002, 2005-2009, 2010, 2011-2016, and 2017-2019 models.
Ignition coils are suitable for 1995, 1996-2002, 2005-2009, 2010, 2011-2016 and 2017-2019 variants.
Moreover, you should also check for coils/ignitors specific for each engine option within the same year vehicle.
There is also the specificity of the ignition switch for each trim level. With introducing keyless start in some versions from 2011-onwards, their compatibility will also be different from the conventional ignition switch.
Drivetrain
Its drivetrain consists of various parts that transfer engine power to the wheels enabling the vehicle to move.
It includes axle assembly and its parts, transmission assembly, transfer case, drive shaft, and different gears for power transfer.
Axle assembly RR and FR 1995, 1996-1997, and 1998-2002 models are compatible. The axle housing on the front is compatible for 1995-2002 and rear 1995-1997 and 1998-2002 models.
The differential assembly is swappable for the 1995-98 models of the SUV.
You can replace the front drive shaft for 1995-2002 and the rear between 1995-98, 2005-2009, 2010, 2011-2013, 2014-2016, 2017-2018, and 2019 model KIA Sportage.
The transfer case assembly matches for 1995-2002 for automatic transmission (AT), 2005-2009, 2010, 2011-2016, and 2017-2019 variants.
The transaxle is compatible between 1995, 1996, 1997-2002, 2011-2013, 2014-2016 model years with Manual transmission (MT), 2005-2006, 2007-2010, 2011-2013,2014-2016, 2017 and 2018-2019 for AWD AT, 2005-2010, 2011-2013, 2014-2016, 2017, 2018-2019 for FWD AT model years.
Transmission is the crucial part of the drivetrain, and matching the gear ratio is imperative to replace between two SUVs.
Engine
It has 3 engine variants, including 2.0L I4, 2.4L I4, and 2.7L V6.
For 2.0L I4, the cylinder block is compatible in 1995, 1996-2002, 2005-2009, 2010, 2011-16 and 2017-2019 variants.
You can replace cylinder heads in 1995, 1996-1997,1998-2002,2005-2006, 2007-2010, 2011-2016 and 2017-2019 models.
Other parts, including crankshaft, engine assembly, and timing cover in 2.0L I4 engine are compatible between 1995, 1996-97, 1998-2002 and 2005-2009, 2011-2013, 2014-2016, and 2017-2019 model SUVs.
You can swap the starter motor in 1995-2002, 2005-2009 with AT, 1995-97, 1998-2002 with MT, 2011-2016, and 2017-2019 models.
The torque converter is swappable for the 1995-1997 year KIA Sportage. Another engine part is the oil pan, which is swappable for 1995, 1996-2002, 2005-2009, 2010, 2011-2013, and 2014-2019 variants..
The 2nd engine option, a 2.7L V6, has a compatible cylinder block, timing cover, oil pan, and starter motor for the 2005-2009 and 2010 versions.
You can replace the cylinder head in 2005-06 and 2007-10 and engine assembly for 2005-10 model years.
The 3rd variant, the 2.4L I4 engine, has a cylinder block, cylinder head, timing cover, and engine assembly compatible with the 2011-2013, 2014-2016, and 2017-2019 models.
In addition, the starter motor matches for 2011-2016 and 2017-2019, while the oil pan is similar for the vehicle’s 2011-2013 and 2014-2019 variants.
You should also check for engine parts for the specific year and trim level of your SUV, as turbocharged variants are also available.
You can also search with a particular part number to find a replacement for perfect fitment.
Interior
You can replace its interior parts include column switch, dash panel, instrument cluster, Radio, and seats.
You can swap the dash panel between 1995, 1996-1997, 1998-2002, 2005-09, 2010, 2011-2012, 2013, 2014-2016 and 2017-2019 models.
Instrument cluster and speedometer are identical for 1995,1996-1997, 1998-2000, 2001-2002, 2005-2007, 2008, 2009, 2010, 2011-2013, 2014-2016 and 2017-2019 year SUVs.
Radio system works with the 1995-1996, 1997, 1998-99, 2000, 2001-2002, 2005-2008, 2009, 2010, 2011-2013, 2014-2016, 2017-2019 models.
There are airbags in the seat, steering wheel, roof, and knee area, and you can swap them between 1996-1997, 1998-2000, 2001-2002, 2005-2009, 2010, 2011-2016, and 2017-2019 variants.
Body parts
With the introduction of a new generation, manufacturers upgrade the body shape, style, and even physical dimensions.
You can replace parts like windscreen glass, windows, doors, front and rear bumpers, roof assembly, grille, center pillar, fenders, door handles, tailgate, and hood between 1995-1997, 1998-2002, 2005-2010, 2011-2016, and 2017-2019 models.
There will be a difference in a few parts, including the grille, front bumper assembly, tail lamp, and windshield glass in the third generation from 2011-2013 and 2014-2016 variants.
Brakes
Front brakes and calipers are compatible for 1995-2002, 2005-2009, 2010, 2011, 2012-2016, and 2017-2019 variants.
You can replace master cylinders between 1995-1997, 1998-2000, 2001-2002, 2005-2007, 2008-2009, 2011-2016, 2017 and 2018-2019 year vehicles.
Moreover, rear brakes and calipers match between 1995-1997, 1998-2002, 2005-2009, 2011-2016, and 2017-2019 variants.
Anti-lock brakes with dynamic body control are swappable for 1998-2000,2001, 2002, 2005-06, 2007, 2008-09, 2010, 2011,2012-13, 2014-16, 2017 and 2018-2019 year SUVs.
Furthermore, you can replace the power brake booster within 1995-1997, 1998-2002, 2005-2009, 2011-2016, and 2017-2019 models.
Wheels
1995-2002 version has 15-inch wheels for all trim levels. The 2005-10 year SUVs have a wheel size of 16-inch for regular trim levels and 17-inch for LX trim with a sport package.
From 2011 to 2016, models have 16-inch for the base, 17-inch for LX, and 18-inch wheels for EX and SX trim levels.
2017-19 models have rim sizes of 17-inch for LX trim, 18-inch for EX, and 19-inch for SX Turbo trim levels.
It has a lug nut pattern of 5X139.7 for 1999-2002 and 5X114.3 for 2005-2020 models.
The thread size for lug nuts remains the same across all generations. However, there is a difference in offset for different groups; you should check for it before replacing it.
Suspension system
Suspension parts, including coil-overs/springs, lower control arm, struts, and the upper control arm, are interchangeable for 1995-1997, 1998-2002, 2005-2010, 2011-2013, 2014-2016, and 2017-2019 models.
Other parts like frame, spindle knuckle, and stabilizer bar are identical for the same model year or adjacent 1-2 years of the SUV for the first generation.
However, 2nd generation vehicles from 2005-2009 have almost all parts compatible.
The key difference for suspension parts can be their physical dimensions and require modifications or cutting/welding work in some instances for their fitment.
Steering parts
Steering columns are different for each year model for the first generation of KIA Sportage except 1998-2000.
You can replace other components, including the gear rack and power steering pump/motor for 1995, 1996-98, 1999-2000, and 2001-2002 model years.
You can swap the steering hub between 1995-1997 and 1998-2002 SUVs.
For the 2nd, 3rd, and 4th generation, most parts work with 2005-2009, 2010, 2011-13, 2014-2016, and 2017-2019 models.
Fuel system
You can replace fuel injectors for 1995, 1996-02, 2005-09, 2011-13 and 2014-16, 2017, and 2018-2019 model years.
You can replace the fuel pump assembly and tank within the 1995, 1996, 1997-98, 1999-2000, and 2001-2002 models from the 1st generation.
Moreover, you can swap them between any two models in the 2nd generation from 2005-2009 models.
For the 3rd and 4th generation, fuel tanks are compatible for 2011-16 and 2017-19 models and pump assembly from 2011, 2012-2013, 2014-2016, 2017, and 2018-2019 year SUVs.
Cooling system
The cooling system contains the radiator assembly, fan, coolant reservoir, pump, and lines to remove heat from the engine.
Radiator assembly, pump, fan motor, and coolant lines are compatible from 1996-2000, 2001-2002, 2005-2009, 2011-2016, and 2017-2019 models.
However, the coolant reservoir, radiator fan, and blades can differ within the same generation models.
Electrical/electronics parts
Electrical and electronic components include alternator, different motors, temperature control system, body control module (BCM), and the engine control module (ECM).
For blower motors, temperature control, and wiper motors, you should swap within the same model year, especially in the first generation.
The alternator is compatible for 1996-2002, 2005-2009, 2011-2013, 2014-2016, and 2017-2019 variants.
Power window motors are available from the 2nd generation onwards and are interchangeable within the same groups.
BCM is specific according to the model year of the SUV and has features like transmission control, anti-theft system, and suspension system control.
ECM is specific for each engine type and model year of your vehicle. You have to reprogram it to work in another SUV.
Do all parts interchange between KIA Sportage FWD and AWD?
You can swap all parts between FWD and AWD models of KIA Sportage except those related to the drivetrain and its components.
The major difference is in the front-wheel-drive (FWD), and all-wheel drive (AWD) models are in the transmission system.
Therefore, these parts, including the transaxle and other components, work between the models and have the same drive mode.
For example, the transaxle is compatible between 2005-2010 models of the SUV with AT for FWD. In comparison, these are swappable between 2005-2006 models for AWD.
The power steering hub and its linkages with wheels, ECM, BCM, and driveshaft are other parts specific for FWD and AWD.
The rest of the features, including the body, interior, engine, and lights, are suitable, as already mentioned in the article.
Are parts between different trim levels of KIA Sportage interchangeable?
It has several trim levels, including LX, EX, SX Turbo, and Base. Their features related to body styling, luxury features, and power rating can vary.
Therefore, these parts are specific for each trim level; you can swap them with the same trim level without any alteration.
For example, the front bumper assembly’s ignition switch, grille, and exterior styling are different for EX, LX, and SX Turbo trim levels.
Moreover, you will also find a difference in wheel rim size for 4th generation models for specific trim levels. SX Turbo is the most expensive of all trim levels and has many luxury and sport-inspired features.
Moreover, its interior, front and back end styling and suspension system are more advanced than others.
Therefore, you require modifications to make it work on other trim levels with limited or full functionality.
