Many people add a lift kit to their Chevy Equinox for mounting larger tires and improved road visibility. In addition, the spacer lift kits have a less challenging installation without changing the chassis of an SUV.
Can You Put a Lift Kit on a Chevy Equinox? You can put a lift kit on a Chevy Equinox by selecting appropriate strut spacers, stabilizing SUV over jacks, using lift pads to avoid component damage, providing free space to suspension, and removing tires. Then, unbolt the shocks, remove them from the frame, discard the sway bar pin from the end link, remove spring coil retainers and reduce the distance of the axle from the jack. Next, access the top side spring, put the coil spacer lift kit on it, raise the jack slightly, connect the axle and spacer assembly in one spot, and reinstall the tires and other removed parts.
Also, it is compatible with the built-in suspension type and the vehicle’s design and indicates the installation of strut spacers.
- 1 What type of lift kit can you put on a Chevy Equinox?
- 2 How to add a lift kit on a Chevy Equinox?
- 3 Does a lift kit change the suspension on a Chevy Equinox?
- 4 How much ground clearance can you get by putting a lift kit on a Chevy Equinox?
- 5 Why would you add a lift kit on a Chevy Equinox?
- 6 How much does it cost to add a lift kit to your SUV?
What type of lift kit can you put on a Chevy Equinox?
You can put a strut spacer lift kit on your SUV with an easy installation method that completes within 2 to 4 hours.
The kit includes two struts, the required hardware, and a manual that contains the instructions for installation.
In addition, the spacer struts consist of aluminum and steel and quickly fit in the shock absorbers of a Chevy Equinox. A spacer kit reduces the cost of the compressor and rack disassembling equipment.
Unlike a suspension leveling kit, a lift kit improves the vehicle’s height by around 1 inch to 3 inches.
It increases the SUV height, provides controlled off-road driving conditions, and saves the replacement cost of spring coils.
As a result, it remains safe for a long time without significant damage.
However, they do not improve the driving performance of an SUV, but it provides a clear road view and keeps the vehicle safe.
How to add a lift kit on a Chevy Equinox?
You can install a spacer lift kit without replacing the standard chassis of an SUV However, it raises the height of an SUV by a few inches, but you can identify a significant difference in the frame.
Stabilize the SUV on a flat surface and turn off the ignition. Also, remove the battery’s negative terminal and leave the system for cooling.
Then, adjust high-quality jacks under the SUV that can bear the heavyweight of the automobile frame without any damage.
In addition, use the standard lifting pads and secure the components from damage. Also, never adjust the axle on the jack because the suspension requires free space during these procedures.
In addition, adjust the axle on the jack and prevent any movement.
Move towards the front side of your SUV, loosen the nuts and bolts of the tires, and remove them. Then, access the shock absorbers, unbolt the shocks, and remove them from the frame.
Now, approach the sway bar, find the screws, loosen them with a screwdriver in an anticlockwise direction and remove the pin from the end link.
Moreover, the end link connects firmly with the sway bar, and you can remove it with ball-joint equipment.
In such circumstances, remove the coils by removing their bolts with an appropriately sized wrench.
In addition, the coil spring has retainers on both sides, and you should remove them before compression activities.
The security of springs is necessary to prevent any sudden damage to the components.
Then, make a secure connection between the internal components and the spring compressor and check their compatibility.
Now, reduce the distance of the axle from the jack but prevent it from free falling. Then, access the spring of the top side and adjust the coil spacer on it.
Now, handle the jack appropriately, slightly raise it, and connect the spacer assembly and axle in an appropriate spot. Also, you can hold the spacer during the mounting conditions that can cause a sudden injury.
However, you can move it around the corners and never move it towards the upper side. As a result, the compressor does not fail and works appropriately.
Fix the spacers on the coil springs and reassemble the removed components. Also, reinstall the retainers on both sides, tighten them with a wrench and fix them.
Then, check the weight-bearing capacity of the axle and ensure its stability. Finally, you can repeat a similar spacer mounting procedure on the rear side of your SUV.
Does a lift kit change the suspension on a Chevy Equinox?
This SUV has a strut-independent suspension, and you can add spacers to lift your vehicle.
These kits raise the truck frame from both sides but never change the built-in suspension of the SUV. Moreover, Equinox has a front suspension with coil springs and a bar.
The rear side suspension includes a 4-link independent suspension system.
Also, you would not purchase extra equipment from installation and replacement procedures.
How much ground clearance can you get by putting a lift kit on a Chevy Equinox?
The spacer lift kits adjust between the frame of an SUV and its body. Moreover, these kits improve the height on the front and rear sides by around 1 inch to 3 inches.
It increases the driving height but does not improve the vehicle’s performance. The spacers come in a package of two components stacked on each other.
They improve the ground clearance from 0.48 inches to 0.95 inches. Also, other customized options can provide a ground clearance of around 1.6 inches to 2.5 inches.
Why would you add a lift kit on a Chevy Equinox?
The body lift kits increase the frame height, but they provide a ground clearance of around 1 to 2 inches.
Improved road visibility
It improves road visibility due to increased body height.
You can identify the road obstacles from a distance, and it saves you from a sudden bumping into dangerous objects.
In addition, the driver avoids the nearby high-speed vehicles by accessing them before the collision.
Mount larger wheels
They provide extra space in the wheel well, and you can mount larger tires. For example, a 2022 Chevy Equinox has a built-in tire size of around P225/65R17 to P225/60R18.
However, you can adjust large tires with appropriate rims. During these installations, consider the position of fender flares and mud flaps and prevent unnecessary scratching.
Less tire damage on off roads
The SUV seems higher, and it improves off-road driving with minimum tire damage. At the same time, the improved height of the SUV repels the road dust, water splashes, and debris.
As a result, its tires can last longer than the standard lifespan. The built-in short tires have a life duration of around 32000 miles to 42000 miles.
It facilitates the adjustment of larger tires. They can last for around 52000 miles to 62000 miles.
How much does it cost to add a lift kit to your SUV?
The average cost to install a lift kit on a Chevy SUV is around $500 to $5000. The front strut spacer lift kits for this vehicle cost you $182 to $184.
These are available on online portals, and you can purchase them from auto part stores at discounted prices.
But, people purchase them for both sides of their SUVs. In addition, the costs are high for the customized options of kits. However, a mechanic can put these on your SUV is around $900 to $10000.
It varies according to the location of a workshop, its popularity, and the skills of a mechanic.
Local service portals across the USA facilitate a similar service for around $500 to $3400 with discounted packages.
In addition, the labor charges are from $170 to $230 per hour.
Moreover, they can complete the procedure in around 1 to 1.5 hours.
